Description
Features:
The Select Hip Abduction machine is a fundamental part of strength training progression. Its adjustable start position allows for easy entry and exit, while the front-mounted stack provides a privacy screen for added comfort.
Frame Specifications
- Main frame: 75 *118*3.0 mm semi-elliptical pipe
- Functional area: 50* 120 *3.0 mm flat oval pipe
- Movement arm: 40 * 80 * 3.0 mm
- Joint pipe: 50 * 100 * 3.0 mm flat oval pipe
- All pipes are Q235 qualified
Upholstery and Guard Cover
The machine features high-density foam upholstery, covered with furniture-grade PU leather, and includes an integral ABS guard cover for durability and comfort.
Pulley System
The pulley system is made of POM material, precision-machined using CNC technology, and includes customized high-quality bearings to withstand high-intensity, long-term use.
Cable and Wiring
The cable is routed inside the pipes for a clean and organized appearance. The Japan-made wire cable (6 * 19 + 1* 75 coated wire) can withstand up to 1400 kg of tension.
Shroud Material
The full shroud is made from 4 mm thick ABS virgin material, ensuring durability and eco-friendliness.
Specs:
N.W.:200kgs/441lbs G.W.:210kgs/463lbs
Installation size: 746*1664*1660mm/ 29*66*65in
Weight stacks: 80kg-16pcs/176lbs-16pcs
