Description
Features:
The Lat Pulldown is a fundamental part of strength training progression. The thigh pads easily adjust to provide stability and comfort, while the straight bar features angled ends to ensure correct arm and wrist positioning during workouts.
Frame Specifications
- Main frame: 75*118*3.0 mm semi-elliptical pipe
- Functional area: 50*120 *3.0 mm flat oval pipe
- Movement arm: 40*80 *3.0 mm
- Joint pipe: 50 *100* 3.0 mm flat oval pipe
- All pipes are Q235 qualified
Seat and Structure
The seat is made from an aluminum alloy arm in a parallelogram structure, featuring a torsion spring adjustment system for convenience and safety.
Upholstery and Guard Cover
The seat is equipped with high-density foam upholstery, covered with furniture-grade PU leather, and includes an integral ABS guard cover for durability and comfort.
Pulley System
The pulley system is made of POM material, precision-machined using CNC technology, and includes customized high-quality bearings to withstand high-intensity, long-term use.
Cable and Wiring
The cable is routed inside the pipes for a clean and organized appearance. The Japan-made wire cable (6 x 19 + 1 x 75 coated wire) can withstand up to 1400 kg of tension.
Shroud Material
The full shroud is made from 4 mm thick ABS virgin material, ensuring durability and eco-friendliness.
Specs:
N.W.:195kgs/430lbs
G.W.:205kgs/452lbs
Installation size: 1245*1068*2215mm/ 49*42*87in
Weight stacks: 90kg-18pcs/198lbs-14pcs
