Description
Features:
The Low Row is a training device designed for back muscle development. Its ergonomically rotating handles allow for natural, user-defined movement, offering greater variety and increased muscular involvement.
Frame Specifications
- Main frame: 75 *118 * 3.0 mm semi-elliptical pipe
- Functional area: 50 * 120 * 3.0 mm flat oval pipe
- Movement arm: 40* 80*3.0 mm
- Joint pipe: 50*100 *3.0 mm flat oval pipe
- All pipes are Q235 qualified
Seat and Structure
The seat is made of an aluminum alloy arm with a parallelogram structure, featuring a torsion spring adjustment system for convenience and safety.
Upholstery and Guard Cover
The seat features high-density foam upholstery, covered with furniture-grade PU leather, and includes an integral ABS guard cover for durability and comfort.
Pulley System
The pulley system is made of POM material, precision-machined using CNC technology, and includes customized high-quality bearings to withstand high-intensity, long-term use.
Cable and Wiring
The cable is routed inside the pipes for a clean and organized appearance. The Japan-made wire cable (6 x 19 + 1 x 75 coated wire) can withstand up to 1400 kg of tension.
Shroud Material
The full shroud is made from 4 mm thick ABS virgin material, ensuring durability and eco-friendliness.
SpecsïŒ
N.W.:195kgs/430lbs
G.W.:205kgs/452lbs
Installation size:746*1914*1660mm/29*75*65in
Weight stacks:80kg-16pcs/176lbs-16pcs
